ioPAC 5500 Hardware Installation
2-2
Basic Installation
DIN Rail Installation Procedure
Installing the ioPAC 5500 on a DIN Rail
The DIN rail attachment plate should already be fixed to the back panel of the ioPAC 5500 when you take it out
of the box. To install the ioPAC 5500 on a DIN Rail, follow below steps.
NOTE
A wall
mount kit can be purchased separately.
STEP 1:
Insert the top of the DIN
rail into the slot just
below the stiff metal spring
.
STEP 2:
The DIN-rail attachment unit will snap into
place
as shown to the right.
Removing the ioPAC 5500 from a DIN Rail
To remove the ioLogik unit from the DIN-rail, simply reverse Steps 1 and 2 above.
