Moxa OnCell G2111 [24/48] Additional information
![Moxa OnCell G2151I [24/48] Additional information](/views2/1201497/page24/bg18.png)
OnCell G2111/G2151I Series AT Command Set
3-9
5. On the bottom of the modem, set DIP switch 1 to OFF, DIP switch 2 to ON, and DIP switch 3 to ON. This
configures the modem for 2-wire RS-485 communication.
Additional Information
• V.25ter recommendation
For commands that are not supported, the OnCell G2111/G2151I Series modem will respond with “ERROR”.
Modulation control, error control, and data compression commands are not recognized. An “ERROR” string
will be returned.
• GSM 07.05 recommendation
07.05 commands that are not described in this manual will not be implemented. An “ERROR” string will be
returned.
• GSM 07.07 recommendation
07.07 commands that are not described in this manual will not be implemented. An “ERROR” string will be
returned
• The ATQ1 command for “Result Code Suppression – not transmitted” is not supported.
AT&W is entered here.
OK is the response from the modem.
