OnCell G2111/G2151I Series GSM/CSD Connection

4-3

5. Type ATH and press Enter to disconnect.

ATTENTION

+++ is the escape sequence, and ATH is the hang

-up command.

For international calls, the local international prefix does not required, but the + character is. You would type

ATD+886289191230.

Answering a CSD Connection

PComm Terminal Emulator can be used to answer a CSD call manually:

1. When the terminal displays “RING”, type ATA and press Enter.

2. Check the STATUS indicator on the front panel. If the LED is steadily on, the CSD connection has been

established successfully. The modem will automatically switch to data mode. At this point, you can proceed

with data communication.

3. PComm Terminal Emulator can be used to configure the modem to answer CSD calls automatically:

4. In the terminal window, type ATS0=x and press Enter. For x, substitute the number of rings that the

modem should receive before answering the call. For example, to answer after the first ring, type ATS0=1.

5. Type AT&W and press Enter.
