OnCell G3100 Series Introduction
1-3
Product Features
All models in the OnCell G3100 series have the following features:
• Quad-band 900/1800, 850/1900 MHz GSM/GPRS/EDGE
• Five-band UMTS/HSPA 800/850/AWS/1900/2100 MHz (OnCell G3100-HSPA only)
• Special design for Japan Softbank (JPS) or NTTDocomo (JPN) operator
• Versatile operation modes, including Real COM, Reverse Real COM, RFC2217, TCP Server, TCP Client, UDP,
Ethernet Modem, and SMS Tunnel
• AT command over Ethernet
• Private IP management software
• Port buffering function to prevent loss of serial data when communication is disrupted
• Secure data access modes including Secure Real COM, Secure Reverse Real COM, Secure TCP Client, and
Secure TCP Server
• Adjustable baudrate feature for easy configuration of custom baudrates
• Redundant DC power inputs
• LED indicators for status and signal level
• 2 digital inputs and 1 relay output
• GuaranLink for reliable connection
• Remote command by SMS
Product Specifications
Note: The OnCell G3100 series has several hardware revisions. Please check the following table to
see which functions are supported by the various revisions.
For Ethernet to Cellular, refer chapter 9 for details. For Virtual Modem Mode, refer chapter 10 for
details.
OnCell Central
Manager
Ethernet Device
<-> Cellular
Virtual Modem Mode
IP Gateway
OnCell G3110 Rev 1.2
– –
OnCell G3150 Rev 1.2
– –
OnCell G3110 Rev 2.0
OnCell G3150 Rev 2.0
OnCell G3110 Rev 3.0
OnCell G3150 Rev 3.0
OnCell G3110-HSPA Rev 1.0
–
OnCell G3150-HSPA Rev 1.0
–
OnCell
G3110/G3150
OnCell
G3110/G3150-HSPA
LAN Interface
Ethernet 10/100 Mbps, RJ45 connector
Protection Built-in 1.5 KV magnetic isolation
Cellular Interface
Standard
Compliance
GSM/GPRS/EDGE GSM/GPRS/EDGE/UMTS/HSPA
Band Selection Quad-band 850/900/1800/1900
MHz
Five-band 800/850/AWS/1900/2100 MHz
Quad-band 850/900/1800/1900 MHz
