VPort 56-2MP System Configuration

4-40

NOTE

Administrators can use the following steps to set up an event schedule:

1. Select Event Type

2. Enable “Event Alarms are active based on weekly schedule”

3. Select the weekday

4. Set the start time

5. Set the duration this event will be active.

6. Save

Event Alarm

Four kinds of event alarm are provided by the VPort for building an intelligent video surveillance system.

Alarm Type Triggered Condition Triggered Action

Video Motion Detection (VMD) 1. VMD 1

2. VMD 2

3. VMD 3

1. Trigger Relay

2. Email

3. FTP

4. HTTP Event Server

5. Record on SD card

CGI Event The CGI trigger message 1. Trigger Relay

2. Email

3. FTP

4. HTTP Event Server

5. Record on SD card

Sequential Snapshot

Always triggered when this function

is enabled

1. Send snapshot via Email

2. Send snapshot via FTP

Digital Input 1. High

2. Low

3. Rising

4. Falling

1. Trigger Relay

2. Email

3. FTP

4. HTTP Event Server

5. Record on SD card

Video Motion Detection

Video Motion Detection (VMD) is an intelligent event alarm for video surveillance network systems. With the 3

area-selectable VMDs and sensitivity/percentage tuning, administrators can easily set up the VMD alarm to be

active 24 hours a day, 7 days a week.
