VPort 56-2MP System Configuration
4-2
System Configuration by Web Console
System configuration can be done remotely with Internet Explorer. To access the server, type the system
configuration URL, http://<IP address of Video Server>/overview.asp, to open the configuration main
page.
There are six configuration categories: System, Network, Video, PTZ, D, and Alarm. A description of each
configuration item is shown in the table below:
Category Item Description and Contents
System General Set Host Name and Date/Time
Accounts Administrator, User, and Demo Account Privileges Management
Local Storage
Configure the local storage settings
Diagnosis Self-diagnostic report with system, communication, power, and LED
status
System Log System Log and operation information
System Parameter System parameter information and Import/Export functions
Firmware Upgrade Remote Firmware Upgrade
Factory Default Reset to Factory Default
Reboot Device will reboot to restart the system
Network General The IP network settings of this VPort
SMTP Server Set up Primary and Secondary SMTP Server and e-mail accounts
FTP Server Set up the Primary and Secondary FTP Server
DDNS Configure Dynamic DNS service
Universal PnP Enable UPnP function
Multicast Setting Set up Multicast (IGMP) Streaming
Accessible IP Set up a list to control the access permission of clients by IP address
SNMP Configure the SNMP settings
ToS Configure ToS (Type of Service)
HTTP Event Server Set up the HTTP Event Server to send the event alarm action
Modbus/ TCP Enable Modbus/TCP function
DynaStream Basic Set up the video frame rate change once an alarm or event is
triggered
Conditions
Set up the event/alarm to trigger Dynastream, and the behavior after
being triggered
Video Image Settings Configure the attributes of the video image
Image Tunning Configure the attributes of the camera
ROI
Configure the ROI (region of interest) settings
Privacy Mask Configure the Privacy Mask settings
Camera Modulation Select the camera’s modulation (NTSC or PAL)
Video Performance Set up the Encode Standard (MJPEG or MPEG4), Size (Resolution),
FPS, and Video Quality
Event Alarm Basic General event alarm settings
Schedule Set up the Alarm schedule
Motion Detection Configure the motion detection alarm
Digital Input Configure the Digital Input Alarm
CGI Event Set up the CGI event alarm
Camera Tamper Configure the Camera Tamper event Alarm
This table can also be found on the System Configuration Overview webpage.
