D
D. Technical Specifications
Camera
Sensor:
1/2.5” HD progressive scan CMOS
Lens:
6.3 to 63 mm auto focus zoom lens
Angle of view (tele
-wide):
• Horizontal: 5.5° to 50.6°
•
Vertical: 3.1° to 29.3°
•
Diagonal: 6.2° to 57°
Illumination:
• Color: 0.2 lux at F1.8
• B/W: 0.05 lux at F1.8
Synchronization:
Internal
White Balance:
ATW, AWB
Electronic Shutter:
AES: On/Off
Fix: 1/50, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 sec
S/N Ratio:
More than 50 dB (AGC off)
ICR Control:
Auto (light sensor control) or DI control
DNR:
Built-in 3D DNR
AGC Control:
On/Off
Backlight Compensation: On/Off
Auto Exposure:
On/Off
Image Rotation:
Flip, Mirror, and 180° rotation
Auto Sense Up:
On/Off, Max. 64x
Image Setting:
Manually tune sharpness
Video
Video Compression:
H.264 (ISO/IEC 14496-10) or MJPEG
Video Output:
via Ethernet
Video Streams:
Up to 3 video streams (2 x H.264 and 1 x MJPEG)
Video Resolution and FPS (frames per second):
NTSC PAL
Size Max. FPS Size Max. FPS
Full HD 1080P 1920 x 1080 30 1920 x 1080 25
HD 720P 1280 x 720 30 1280 x 720 25
SVGA 800 x 600 30 800x 600 25
Full D1 720 x 480 30 720 x 576 25
4CIF 704 x 480 30 704 x 576 25
VGA 640 x 480 30 640 x 480 25
CIF 352 x 240 30 352 x 288 25
Note: Up to 30/25 FPS for each of 3 independent streams at max resolution.
