VPort 56-2MP System Configuration
4-44
Setting Description Default
Enable the
digital input
alarm
Enable or disable the digital input alarm Disabled
Trigger Conditions
Setting Description Default
High The DI is always in the “High” state after an alarm is detected.
Disabled
Low
The DI is always in the “Low” state after an alarm is detected.
Disabled
Rising The DI works from state
“Low” to state “High” and then back to
state “Low” when an alarm is detected.
Disabled
Falling
The DI works from state “High” to state “Low” and then back to
state “High” when an alarm is detected.
Disabled
Trigger Actions
Setting Description Default
Trigger Relay 1 alarm Once this VMD is triggered, the VPort will
trigger relay 1. Note
that relay behavior will follow the configuration in alarm basic
setting page.
Disabled
Send snapshot image
via E-mail
Once this VMD is triggered, the VPort will send the snapshot
images set in the Event Alarm/Basic page to the E-mail
addresses, which are set in the Network/ SMTP Server page.
Disabled
Send snapshot image
via FTP
Once this VMD is triggered, the VPort will send the snapshot
images set in the Event Alarm/Basic page to the FTP server,
which are set in the Network/ FTP Server page.
Disabled
Send message via HTTP
Event Servers
Once this VMD is triggered, the VPort
will send the message set
in HTTP Action Setting to the HTTP event servers, which are set
in the Network/ HTTP Event Server page.
Disabled
Record video on SD
card for Sec
Once this VMD is triggered, the VPort will record the video on
the SD card for a configured time period.
Disabled
HTTP Action Setting
Setting Description Default
Server 1, 2, 3, or 4 Select the HTTP event server for sending the HTTP action Disabled
Blank text box For customizing the message to the HTTP event server. Blank
