VPort 56-2MP System Configuration
4-11
General Settings
Setting Description Default
IP address Variable IP assigned automatically by the DHCP server, or fixed
IP assigned by the Administrator.
192.168.127.100
Subnet mask Variable subnet mask assigned automatically by the DHCP
server, or a fixed subnet mask assigned by the Administrator.
255.255.255.0
Gateway Assigned automatically by the DHCP server, or
assigned by the
Administrator.
Blank
Primary DNS
Enter the IP address of the DNS Server used by your network.
After entering the DNS Server’s IP address, you can input the
VPort’s url (e.g., www.VPort.company.com) in your browser’s
address field, instead of entering the IP address.
Obtained
automatically from
the DHCP server, or
left blank in
non-DHCP
environments.
Secondary DNS
Enter the IP address of the DNS Server used by your network.
The VPort will try to locate the secondary DNS Server if the
primary DNS Server fails to connect.
Obtained
automatically from
the DHCP server, or
left blank in
non-DHCP
environments.
HTTP
Setting Description Default
HTTP Port
(80, or 1024
to 65535)
HTTP port enables connecting the VPort to the web. 80
HTTPS port (80, or
1024 to 65535)
HTTPS port number for communication encryption (do not set
the same port number as the HTTP port)
443
HTTP mode HTTP mode Select the HTTP transmission mode: HTTP Only
or
HTTP +
HTTPS
HTTP Only
RTSP Streaming
The VPort 56-2MP supports standard RTSP (Real Time Streaming Protocol) streaming, which means that all
devices and software that support RTSP can directly acquire and view the video images sent from the VPort
56-2MP without any proprietary codec or SDK installations. This makes network system integration much more
convenient. For different connection types, the access name is different. For UDP and TCP streams, the access
name is udpStream. For HTTP streams, the access name is moxa-cgi/udpstream_ch<channel number>.
For multicast streams, the access name is multicastStream_ch<channel number>. You can access the
media through the following URL: rtsp://<IP address>:<RTSP port>/<Access name> for software
that supports RTSP.
Setting Description Default
RTSP Port An RTSP port is similar to an HTTP port, which can enable the
connection of video/audio streams by RTSP.
554
