1-153
Appendix 6
List of Specifications by Model
Table below are specifications required when editing printing for each model
such as memory size and the maximum page length.
Model names
Items CL-S621
CL-S521
CL-S700
Series
CLP-9000 CLP-8301
on-board SD-RAM
[Byte]
1024K 1024K 512K 512K
on-board flash memory
[Byte]
1024K 1024K 512K 512K
Maximum page length 32inches 40inches 40inches 40inches
Number of maximum
print fields
400 400 400 400
Field register data area
[Byte]
20K 20K 20K 20K
Bit map area [Byte] 1892K 1660K 1922K 4652K
Reception buffer area
[Byte]
16K 16K 16K 16K
Command buffer [Byte] 128K 128K 128K 128K
Paper setting Left end reference Centering
RTC Uninstalled With optional settings
With standard equipment models
