1
-
3
Fig. 1 Command summary
System level commands
Start with "SOH" or "STX"
and end with a “CR”
Commands which start with "SOH"
Executed as soon as they are received
(For example: printing halt, output of printer status, etc.)
Commands which start with "STX"
Executed in order after they are received into the
reception buffer
(For example: sensor sw itching, memory card
maintenance, etc.)
"STX" + "L" ↓ ↑ "E" (with printing)
"X" (without printing)
Label format commands Print parameter control
End with a "CR" Character data definition commands
Bar code definition commands
Graphic commands
Other commands
