Loewe Viewvision DR+ [29/66] Hdmi operation

29 -

HDMI (DVI) connection

The HDMI connection (High Definiton Multimedia Interface) allows digital picture

and sound transmission via a connecting cable, e.g. to Loewe Flat TV sets. The

digital picture and sound data are transmitted without data compression and there-

fore lose none of their quality. In the equipment connected, no analogue/digital

conversion is necessary, which might also have lead to losses in quality.

DVI signals can be also be reproduced by the HDMI connection using a DVI/HDMI

adapter cable. This is possible because HDMI is based on DVI and is downwardly

compatible. That means that the digital video signals are transmitted via HDMI

- no audio signals are transmitted, though. In addition, both use the same copy

protection method HDCP (High Definition Content Protection).

Switch off the TV set/monitor with HDMI connection and

recorder.

Connect recorder to TV set/monitor via HDMI connection as

described on page 13.

Switch on the TV set/monitor.

Switch on the recorder after 30 seconds.

set (see user guide TV set).

➠ DVI: If a DVI-HDMI adapter cable is used for transmission,

connect the analog or digital audio outputs on the recorder with

the corresponding inputs of the TV set as described on pages 13

and 14.

Leave the existing SCART connection as it is to record from the TV.

HDMI operation

Switch the TV set over to the HDMI AV input (takes place auto-

matically in connection with a -Loewe Flat-TV set, see page 13).

Press the RES button on the recorder repeatedly to set the desired

picture resolution (e.g. 576i, 576p, 720p, 1080i).

➠ You can only set resolutions which your TV set/monitor is

capable of. For optimum picture quality, select the resolution

1080i on the recorder.

Open the disc drawer.

Insert the selected disc in the drawer with the side to be played

facing down.

Close the drawer.

Call main menu.

34 Select FILM.

56 Select HDD, HDD DivX or Disc.

Confirm selection with OK.

A menu appears on the screen.

5 634Select title on DVD.

Depending on the medium, playing starts automatically or is

started with the Play button or you have to make entries in the

menu.

➠ The other sockets (VIDEO OUT, S-Video and Component Video) have no

function during the HDMI mode.

➠ With an HDMI connection the audio scanning frequency is only 48 kHz, even

when selecting 96 kHz.

➠ This recorder performs no internal (2-channel) decoding of DTS soundtracks.

In order to enjoy DTS multi-channel surround sound, this recorder must be

connected by one of the digital audio outputs to a DTS-compatible receiver.

➠ If the “Dolby Digital” or “MPEG” option has not been set to “PCM” in the

Sound menu (page 22), no sound is output through the TV set.

➠ The HDMI connection to the recorder is operated as a signal output. Please

proceed as described on page 44 if you want to record from an external signal

source with the recorder.

HDMI mode
