Loewe Articos 32 [10/34] Daily handling

Loewe Articos 32 [10/34] Daily handling
10
Daily handling
Switching on/off
Your TV set is equipped with an eco-standby
power supply unit. The power consumption drops
to low power in standby mode. If you want to
save even more energy, switch the set off with
the On/Off switch. However, please note that
EPG data are then lost and timer recordings
programmed on the Digital Recorder set will not
be carried out.
However, please note that EPG data will be lost
and programmed timer recordings for the Digital
Recorder will not be performed.
If the TV is switched on, you can
switch it off with the blue On/Off
button on the remote control.
The red standby LED on the set
lights up. If the green LED also
lights, a timer recording is in
progress on the VCR or built-in
digital recorder, EPG data is
being acquired or radio mode
without screen display is active.
From standby it is best to switch
back on with the blue On/Off
button or with a numeric key
(station 0 – 9). The green operat-
ing LED then lights up.
When you switch on the TV with
OK, you see the station table and
can choose a station.
Switch on in the radio mode.
The display and the On/Off switch are combined
in one unit.
None of the indicators lights up
when you switch off the TV set
with the On/Off button on the
set.
Switch on the TV set with the
On/Off button on the set when
it is switched off.
Changing channels
Channels up/down (only
favorite stations if these are
shown in the station table).
With the numeric keys on the remote control
The set has a dynamic memory with 220 (with
DVB 1470) memory slots. If up to 9 stations are
stored, you only need to enter one number, up
to 99 two numbers, up to 999 three numbers
and above 999 four numbers (please look in the
station table to find out how many stations have
been stored).
1-digit stations
Keep the button 0 – 9 pressed
for one second, the channel
then changes immediately.
Or press the button 0 – 9 briefly,
the channel then changes after
2 seconds (changes immediately if
only 9 stations are stored).
2-digit stations
Keep the second numeric key
pressed for one second, the chan-
nel then changes immediately.
Or press both numeric keys briefly,
the channel then changes after
2 seconds (immediately when
up to 99 stations are stored).
3-digit stations
Keep the third numeric key
pressed for one second, the chan-
nel then changes immediately.
Or press the three numeric keys
briefly, the channel then changes
after 2 seconds (immediately when
up to 999 stations are stored).
4-digit stations
Press the four numeric keys
briefly, the channel then changes
immediately.
Depending on how many stations have been
stored, you can place one or more zeros in front
of the number and select for example station
7 = 07 or 007 or 0007.
With the station table
Call the station table with OK
Mark the station (if possible the
marked station is shown in the PIP
picture)
Mark with numeric keys
Call the marked station
Sort alphabetically/numerically
(blue button)
Display favorite stations only
(yellow button)
Call Audio/Video programs – AV selection
for playing AV equipment
(see also page 20).
Select AV socket or VIDEO for
VCR station.
long
short long
short short long
all short
...
OK
P+
OK
P–
V— V+
pqrs
abc
pqrs
abc
pqrs
abc
pqrs
tu
v
OK
OK
AV
wxyz
OK
AV
OK
VIDEO AV1 AV2 AV3 AVS
AV Selection
Channel overview: TV Numerical
AVS
AV3
AV2
AV1
0 VIDEO
1 ARD
2 ZDF
3 SAT.1
4 RTL
5 VOX
6 S–RTL
7 N–TV
8 DSF
9 TM3
10 PRO7
11 RTL 2
12 WDR 3
13 BR 3
14 HR
15 MDR 3
0 9
Select and
press OK to proceed
Menu
Info
End
Change sorting
Change programs
DR archive
Favourite programs
... Select program:
OK
INFO
MENU
END
Channel overview: TV Alphabetical
ARD
BR-ALPHA
BR3
CNN INT.
CAM
DSF
DVD
EUROSPRT
HOT
HR
KIKA
MDR 3
N–TV
✳ABCDEFGHIJKLMNOPQRSTUVWXYZ
Select and
press OK to proceed
Menu
Info
End
Change sorting
Change programs
DR archive
Favourite programs
OK
INFO
MENU
END
RADIO
BAQ2550H_31310_021_4_GB 22.07.2004, 10:15 Uhr10
