24
Problem
Connection of a decoder does not work or does
not work properly
No sound through the TV loudspeakers
All menus appear in the wrong language
Digital Link Plus does not work
Various characters are displayed incorrectly in
teletext
Possible cause
a) The signal is not decoded because the correct
decoder programs have not been selected in
the TV menu – Connections
b) The sound is missing in decoder mode because
the wrong decoder sound is allocated in the TV
menu – Connections
a) The item ”Sound from...” in the Sound menu
under ”Sound” is not set to ”TV”
b) Nothing is inserted in the 9-pole cube socket
on the back of the set
The wrong menu language has been set
a) The VCR has not been logged in as a Digital
Link Plus device or has been connected to the
wrong socket
b) The Euro-AV cable is not fully wired
(Pin 10 not wired)
c) Some video recorders can only take over the
stations from the TV in initial installation
d) All or some terrestrial or cable stations are
stored at station slots ≥ 99
The wrong character set is set in the teletext
menu
Remedy
a) Follow the instructions in the TV menu –
Connections again and select the appropriate
decoder programs
b) Follow the instructions in the TV menu –
Connections again and select the right sound
source (decoder, TV or Autom.), see instruc-
tions of the decoder
a) Change the setting to ”TV”
b) Either a dummy plug with bridges, Loewe
Concertos, the transmitter for the home auto-
mation or a subwoofer must be plugged into
the cubic socket
Set your menu language:
1. Switch off picture-in-picture (PIP) and switch
off all on-screen displays (END button)
2. Call the TV menu (MENU button)
3. Select the last menu item and press OK
4. Select the last menu item on the last page
and press the OK button
5. Now select the right language and...
6. ...confirm with OK
a) Log in the Digital Link Plus VCR under ”Con-
nections” and connect according to the dia-
gram
b) Change the Euro-AV cable
c) Reinstate the original state (ex-factory) of the
VCR (see operating instructions of the VCR)
d) Sort the terrestrial and cable stations so that
they are between 1 and 99
Set the right character set: Teletext menu – Set-
tings – Character set – Standard or the appropri-
ate character set.
What to do when...
BAQ2550H_31310_021_4_GB 22.07.2004, 10:15 Uhr24
