- 48
The “Title List-Original”
Menu
VR
The playlist (see page 49) is created and edited in
the “Title List-Original“ menu, titles can be deleted
and other changes can be made to the original
content of the disc. Different playlists (dependent
on the program with an audio CD) can be created
and edited.
The individual titles can be played directly
from the menu. The unit must be in stop mode in
order to edit a title in this menu.
Press DISC-M/
to call up the “Title List-
Original“ menu.
With more than 6 titles use / to display
the previous/next page.
Press
to quit the “Title List-Original“
menu.
TITLE 1
DVD-RW
1H 5M
Free
HQ
7/12
0:16:00
TITLE 2
1/12
9/12
0:35:00
TITLE 3
10/12
0:30:00
TITLE 4
13/12
0:08:00
TITLE 5
16/12
0:10:00
TITLE 6
19/12
0:15:00
Playlists Close
TEXT
InfoSelect
INFO
Title List
- Original
END
OK
To display the Title List-Original options, select
the desired title and press OK.
The options are displayed on the left side of the
menu.
Use / to select an option, and press OK
to confi rm
Play: Starts playing the selected title.
Play
Chapter List
Delete
Protect
Edit
Playlists
Redo
Rename
Delete Part
Undo
Chapter List: Changes to the “Chapter
List-Original List“ for the selected title.
Delete: Deletes the selected title (see page
50).
1.
2.
•
•
•
Protect: Prevents inadvertent changing or
deleting of a title (see page 57).
Edit: Contains the following editing op-
tions:
Rename: Edits the title name.
Delete part: Deletes a part of the title.
Undo: Undoes the last deletion
(see page 55).
Redo: Redoes the undo action
(see page 55).
Playlists: Adds the selected title to the end
of a playlist of your choice.
Press
repeatedly to quit the “Title List-
Original“ menu.
Note: Press to display more detailed infor-
mation about the selected title.
The “Chapter List-Original”
Menu
VR
Press DISC-M/
to call up the “Title List-
Original“ menu.
Use to select the title for which you
want to display the corresponding chapter list
and press OK.
The options are displayed on the left side of the
menu.
Use / to select the “Chapter List“ option,
and press OK.
The “Chapter List-Original“ menu is displayed on
the screen.
Chapter List
1/9
TITLE 1
7/12 Su30M56S
- Original
Playlists
TEXT
END
OK
Select
Close
•
•
*
*
*
*
•
3.
1.
2.
3.
To display the “Chapter List-Original“ menu op-
tions, select the desired chapter and press OK.
The options are displayed on the left side of the
menu.
Use / to select an option, and press OK
to confi rm.
Play
Title List
Delete
Combine
Playlists
Play: Starts playing the selected chapter.
Title list: Changes to the “Title List-Origi-
nal“ menu (see left side of this page).
Delete: Deletes the selected chapter
(see page 54).
Combine: Combines two chapters into one
(see page 56).
Playlists: Adds the selected chapter to the
end of a playlist of your choice
(see page 53).
Press
repeatedly to quit the “Chapter
List-Original“ menu.
4.
5.
•
•
•
•
•
6.
Title List and Chapter List (VR)
