-9-
(9) Do not attempt to disassemble the storage battery or the charger.
Special devices, such as a thermostat, are built into the storage battery and charger to
permit rapid charging. Incorrect parts replacement and/or wiring will cause malfunctions
which could result in fire or other hazards. Instruct the customer to bring these units to an
authorized service center in the event repair or replacement is necessary.
(10) Disposal of the storage batteries
Ensure that all customers understand that storage batteries should be turned into any Hitachi
Power Tool sales outlet or authorized service center when they are no longer capable of
being recharged or repaired. If thrown into a fire, the batteries may explode, or, if discarded
indiscriminately, leakage of the cadmium compound contained in the battery may cause
environmental pollution.
B. Caution Plate
(1) The following cautions are listed on the caution plate attached to the Type BSL 1430
storage battery.
7-2. Particular Cautions for Stud Cutter
(1) When operating the switch, carefully ensure that fingers are kept away from the cutters.
To enhance safe operation, the Model CL 14DSL is provided with a cover for the moving
portion of the cutters, a housing shaped so that fingers are kept away from the cutters, a
switch without a stopper, and other safety features. However, the opening to the cutters
must be exposed to permit operation. Should the switch be turned on inadvertently
when the fingers are carelessly near the cutters during replacement or cleaning of the
cutters, while carrying the tool, or at any other time, serious injury could result. The
customers should be cautioned to keep fingers away from the cutters whenever the
storage battery is installed in the tool.
(2) The Model CL 14DSL is designed for cutting mild steel studs. If the tool is used for
cutting brass or stainless steel studs, the threads of the studs will be deformed so that
nuts cannot be applied. In addition, as use of the tool to cut hardened bolts, different-
sized studs, reinforcing rods, etc. will cause damage to the main body, the customers
should be cautioned never attempt to use the tool for such purposes.
(3) Carefully ensure that replacement cutters are appropriate for the stud sizes. As use of
wrong-sized cutters will cause damage to the studs and/or cutter blades, the customers
should be cautioned to ensure that correct cutters are used.
(4) Perform cutting only after confirming that the threads of the stud cutter properly engage
the threads of the stud. If the threads are not properly engaged, damage to the threads
of the stud during cutting may make the stud unusable, and/or the cutter blade may be
damaged.
(5) If the cutters are not mounted in the proper direction, or if the fastening hexagon socket
head bolts are not properly tightened, it will cause damage to the cutters and the main
body of the tool. Instruct the customer to ensure that the cutters are properly mounted.
