-3-
4-1. Selling Point Descriptions
(1) Light weight 2.9 kg
Thanks to adopting the slide-type lithium-ion battery, this new model weighs only 2.9 kg. In
spite of the higher voltage compared to the Model CL 10D2, this model is 0.3 kg lighter than
the Model CL 10D2.
(2) Cutting capacity per single charge: 660 times (M10 mild steel)
Thanks to the higher voltage compared to the Model CL 10D2, larger cutting capacity per
single charge is materialized.
Table 1
Stud size and material CL 14DSL CL 10D2
Battery BSL 1430 EB 1230H
M10 mild steel 660 550
M8 mild steel 1,020 850
M6 mild steel 1,520 1,270
W3/8” mild steel 740 620
Cutting capacity may vary depending on ambient temperature, characteristics of the battery,
condition of the cutter, etc.
(3) Equipped with lightweight and high-capacity (3.0 Ah) lithium-ion battery
Type BSL 1430 lithium-ion battery is substantially lighter than the current Ni-MH batteries in
spite of its high voltage.
Table 2
BSL 1430 EB 1230H
Voltage (V) 14.4 12
Capacity (Ah) 3.0 3.0
Weight (g) 520 680
Type BSL 1430 lithium-ion battery is equipped with the overdischarge protection circuit,
overload protection circuit, and voltage monitoring circuit for each cell to prevent shortening of
the battery life due to overdischarge (overuse) or overcharge (excessive charging) of the
battery. The number of charging/discharging is about 1,500.
Precautions for use of the Type BSL 1430 lithium-ion battery
Type BSL 1430 lithium-ion battery is equipped with a protective function that automatically
stops output to extend the battery life. The motor may stop automatically in either of the
following case 1) or 2) even if the switch is depressed continuously during operation. This is
because the protective function is activated. The battery is not faulty.
1) The motor automatically stops when the remaining battery level is low (when the battery
voltage is decreased to about 8 V). Charge the battery immediately in such case.
2) The motor may stop if the Model CL 14DSL is overloaded. In such case, release the switch
and eliminate the cause of the overload problem. Then the Model CL 14DSL will be
operable.
Please instruct the customers on the above precautions.
