PART
S
CL 14DSL
DESCRIPTION REMARKS
1 327-322 HOUSING (A). (B) SET 1
2 319-402 PUSHING BUTTON (A) 1
3 327-319 SPRING 1
4 301-653
TAPPING SCREW (W/FLANGE) D4X20 (BLACK) 10
5 NAME PLATE 1
6 968-643 RETAINING RING (E-TYPE) FOR D4 SHAFT 1
7 944-458 HEX. BAR WRENCH 4MM 1
8 329-083 BATTERY BSL 1430 (EUROPE) 2 INCLUD. 504
9 CAUTION PLATE (B) 1
10 HITACHI LABEL 1
11 319-401 HOOK 1
12 327-321 SWITCH 1
13 305-558
TAPPING SCREW (W/FLANGE) D5X25 (BLACK) 4
14 307-624 RETURN SPRING 1
15 307-622 GEAR COVER 1
16 629-VVM BALL BEARING 629VVC2PS2L 1
17 319-407 THIRD PINION 1
18 319-406 SECOND GEAR 1
19 608-VVM BALL BEARING 608VVC2PS2L 1
20 609-VVM BALL BEARING 609VVC2PS2L 1
21 939-544 RETAINING RING FOR D15 SHAFT (10 PCS.) 1
22 302-714 WASHER 1
23 310-254 RING GEAR 1
24 319-405 SECOND PINION 1
25 319-404 IDLE GEAR 2
26 307-609 NEEDLE 2
27 307-608 WASHER 1
28 600-1VV BALL BEARING 6001VVCMPS2L 1
29 327-320 MOTOR 1
30 998-471 HEX. SOCKET HD. BOLT (W/FLANGE) M5X1
2
3
31 319-393 FINAL GEAR 1
32 939-546 RETAINING RING FOR D18 SHAFT (10 PCS.) 1
33 307-606
MACHINE SCREW (W/WASHERS) M4X20 (BLACK) 2
34 329-843 COVER 1
35 319-396 BOLT (A) 1
36 987-203
SEAL LOCK SCREW (W/SP. WASHER) M4X12 2
37 319-398 RETURN PLATE 1
38 319-397 BRACKET (A) 1
39 931-875 TAPPING SCREW D5X35 2
40 319-395 BRACKET (B) 1
41 949-574 LOCK NUT M12 (10 PCS.) 1
42 309-180 STUD GUIDE ASS'Y 1 INCLUD. 43, 44
43 949-458 SPRING WASHER M10 (10 PCS.) 1
44 309-621 BOLT W3/8X75 1
45 998-486 SPECIAL BOLT M5X9 2
46 308-779 SPACER M8 (10 PCS.) 2
47 308-564 CUTTER ASS'Y M8 (1 PAIR) 2 INCLUD. 46
48 327-317 ROLLER (A) 1
49 327-318 ROLLER PIN 1
50 319-394 CAM SHAFT 1
- 2 - 3 - 08
*ALTERNATIVE PARTS
