-4-
Indicator
lamp
Remaining battery level
High
(about 60% or higher)
Medium
Low
(about 30% or lower)
Charge the battery
immediately.
(4) Equipped with the remaining battery level indicator
The Model CL 14DSL is equipped with the remaining battery level indicator. The remaining
battery level can be checked with a single touch of a button for operators' convenience.
Note
• The indicator lamp does not light even
though the remaining battery level
indicator switch is pressed unless the
battery is set to the Model CL 14DSL and
the trigger switch is pulled once.
• The strength indicator lamp or the single/
continuos operation indicator lamp may
go out immediately when the remaining
battery level is low and the protective
function is activated even if the switch is
depressed. This is not faulty.
