Tp-Link T2700G-28TQ [5/36] Contents

Contents

Chapter 1 Introduction ———————————— 01

1.1 Product Overview .........................................01

1.2 Appearance .................................................01

Chapter 2 Preparing For Installation —————— 05

2.1 Package Contents ......................................... 05

2.2 Safety Precautions ........................................ 05

2.3 Installation Tools ..........................................07

2.4 Installation & Connection Flow ......................07

Chapter 3 Installation ————————————— 09

3.1

Installing the Switch on a Desktop

....................09

3.2

Installing the Switch Into a 19-inch Rack

...........09

3.3

Installing & Removing the Power Supply Module

...10

3.4

Installing & Removing the Interface Card

........11

3.5

Stacking Using Interface Card on Rear Panel

....12

Chapter 4 Lightning Protection ———————— 14

4.1 Cabling Reasonably ......................................14

4.2 Connect to Ground .......................................16

4.3 Equipotential Bonding ................................... 17

4.4 Use Lightning Arrester ..................................18

Chapter 5 Connection ————————————— 19

5.1 Ethernet Port ...............................................19

5.2 SFP/SFP+ Port .............................................19

5.3 Console Port ................................................19

5.4 Verify Installation .........................................20

5.5 Power on via Power Supply Module .............20

5.6 Power on via Redundant Power Supply .........21

5.7 Initialization .................................................22

Chapter 6 Conguration ———————————— 23

6.1 Congure the Switch via GUI ........................23

6.2 Congure the Switch Using CLI .....................24

Appendix A Troubleshooting —————————— 29

Appendix B Hardware Specications —————— 30
