24
Stackable L2+/L3 Managed Switch
Figure 6-3 Main Page of the Switch
6.2 Configure the Switch Using CLI
You can log on to the switch and access the CLI by the following two methods:
■
Log on to the switch by the console port on the switch.
■
Log on to the switch remotely by a Telnet or SSH connection through an Ethernet
port.
■
Logon by a Console Port
To log on to the switch by the console port on the switch, please take the following
steps:
1. Connect the PCs or Terminals to the console port on the switch by a provided cable.
2. Click Start
→
All Programs
→
Accessories
→
Communications
→
Hyper Terminal to open
the Hyper Terminal as the following figure shown.
Figure 6-4 Open Hyper Terminal
Configuration
