Tp-Link T2700G-28TQ [8/36] Stackable l2 l3 managed switch
![Tp-Link T2700G-28TQ [8/36] Stackable l2 l3 managed switch](/views2/1210081/page8/bg8.png)
03
Stackable L2+/L3 Managed Switch
LED Status Indication
M1,M2
On
An SFP+ transceiver/cable is connected to the
corresponding port of the Interface Card, and it is
connected to a 10Gbps device, but no activity
Flashing
A 10Gbps device is connected to the corresponding
port of the Interface Card
and transmitting data
Off
1. No Interface Card is connected
2. No SFP+ transceiver/cable is connected to the
installed Interface Card
3. An SFP+ transceiver/cable is connected to the
corresponding port of the Interface Card, but it is
not connected to a device
Port Feature
Model
10/100/1000Mbps
RJ45 Port
Console
Port
1000Mbps
SFP Port
10Gbps SFP+
Port
T2700G-28TQ 24 1 4 (Combo)
4 (2 fixed + 2
optional)
T3700G-28TQ 24 1 4 (Combo)
4 (2 fixed + 2
optional)
10/100/1000Mbps Port
Port 1-24, designed to connect to the device with a bandwidth of 10Mbps, 100Mbps
or 1000Mbps. Each has a corresponding Link/Act LED.
SFP Port
Port 21F-24F,
designed to install the SFP transceiver. These four SFP transceiver slots
are shared with the associated RJ45 ports. The associated two ports are referred as
a
“
Combo
”
port, which means they cannot be used simultaneously, otherwise only
RJ45 port works. The SFP ports support 1000M SFP module connection only.
SFP+ Port
Port 25-26, designed to install the 10Gbps SFP+ transceiver or SFP+ cables.
T3700G-28TQ also provides an interface card slot on the rear panel to install the
expansion card (TX432 of TP-LINK for example). If TX432 is installed, you get
another two 10Gbps SFP+ ports.
Unit ID LED
Designed to display the stack Unit ID of the switch.
For the switch that does
not join any stack system, it displays its default
Unit ID. To modify the default
unit number, please logon to the GUI of the switch and go to
Stack
→
Stack
Management
→
Switch Renumber page.
