![Tp-Link T2700G-28TQ [7/36] Stackable l2 l3 managed switch](/views2/1210081/page7/bg7.png)
02
Stackable L2+/L3 Managed Switch
LEDs
LED Status Indication
Power
On The switch is powered on
Off The switch is powered off or power supply is abnormal
Flashing Power supply is abnormal
System
Flashing The switch works properly
On/Off The switch works improperly
RPS
On
Green
Both the Power Supply Module and the redundant
power supply work properly
Yellow
The
Power Supply Module
works improperly, but the
redundant power supply works properly
Off
The switch is not connected to any redundant power
supply
FAN
Green All the fans work properly
Yellow Not all the fans work properly
Master
On
The switch works as master in the stack system, or
does not join any stack system
Off The switch works as slave in the stack system
Module
On(green)
An Interface Card is connected to the switch and works
properly
Flashing(yellow)
An Interface Card is connected to the switch, but
works improperly
Off No Interface Card is connected to the switch
Link/Act
(Por t 1-24)
Green
On
A 1000Mbps device is connected to the corresponding
port, but no activity
Flashing Data is being transmitted or received
Yellow
On
A 10/100Mbps device is connected to the corresponding
port, but no activity
Flashing Data is being transmitted or received
Off No device is connected to the corresponding port
21F-24F
On
An SFP transceiver is connected to the corresponding
port, and it is connected to a device, but no activity
Flashing
A 1000Mbps device is connected to the corresponding
port and transmitting data
Off
An SFP transceiver is connected to the corresponding
port, but it is not connected to a device, or no SFP
transceiver is connected
25, 26
On
An SFP+ transceiver/cable is connected to the
corresponding port, and it is connected to a 10Gbps
device, but no activity
Flashing
A 10Gbps device is connected to the corresponding
port and transmitting data
Off
An SFP+ transceiver/cable is connected to the
corresponding port, but it is not connected to a device,
or no SFP+ transceiver/cable is connected
