Chapter 4. Operation
13
Or
Press the MANUAL/AUTO Button.
Screen Saver
To protect the screens, when the CS261 is in Auto Mode or Manual Mode and
no one is accessing the computer, both monitors will display a black
background. If one of the consoles accesses the computer, the black
background screen will disappear. To enable this function, set DIP switch pin
2 to the On position.
DIP Switch Settings Table
Note: 1. Press a DIP switch pin down to turn it on and up to turn it off.
2. For best results, set the DIP switch pin before turning on both the
CS261 or the computer.
DIP Switch Pins Function
1 2 3 4
On X X X RS232 Command Function Enabled
Off X X X RS232 Command Function Disabled
X On X X Screen Saver Enabled
X Off X X Screen Saver Disabled
X X On On Private Mode Enabled: Console 1 is the Privileged User
X X On Off Private Mode Enabled: Console 2 is the Privileged User
X X Off On Private Mode Disabled
X X Off Off Private Mode Disabled
