CS261 User Manual
v
Package Contents
The basic CS261 package consists of:
1 CS261 2-Port DVI Computer Sharing Device
1 Custom KVM Cable Set (1.8m)
1 Power Adapter
1 User Instructions*
Check to make sure that all the components are present and that nothing got
damaged in shipping. If you encounter a problem, contact your dealer.
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit, and/or any of the
devices connected to it.
* Features may have been added to the CS261 since this manual was printed.
Please visit our website to download the most up to date version of the
manual.
© Copyright 2016 ATEN® International Co., Ltd.
Manual Part No. PAPE-0370-AT1G
Manual Date: 2016-01-12
ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved.
All other brand names and trademarks are the registered property of their respective owners.
