Chapter 4. Operation

information). The Timeout Period cannot be applied in Manual Mode and

Private Mode.

Multiple EDID Selection

Users can select from Remix mode, Port1 mode and ATEN Default EDID

mode, and from three resolutions. Multiple EDID selection can help improve

video quality.

Users can select a desired EDID mode via Hotkeys (see Hotkey Settings Mode

Summary Table, page 17, for more details).
