Chapter 1. Introduction
9
No. Component Description
1 USB 2.0
Hub
USB peripherals (printers, scanners, etc.) can plug into this/
these port(s) (this may require an extra power adapter).
2Console
Port Section
CS1762
A – The cables from your DVI monitor, speakers, and
microphone plug in here. Each connector is marked with an
appropriate icon to indicate itself.
Note: The CS1762
A’s console USB keyboard and USB
mouse ports are located on the unit’s front panel.
CS1764A – The cables from your DVI monitor, USB
keyboard, USB mouse, speakers, and microphone plug in
here. Each connector is marked with an appropriate icon to
indicate itself.
3 KVM Port
Section
The cables that link the switch to your computers plug in
here. Each KVM port section is comprised of a microphone
jack, speaker jack, USB type B socket and a DVI connector.
4 Power Jack The power adapter cable plugs into this jack.
