CS1762A / CS1764A User Manual

HSM Summary Table

After invoking HSM (see page 22), key in one of the following keys to perform

the corresponding function:

Key Function

[H] Toggles between the default ([Num Lock] [-]) and alternate

([Ctrl] [F12]) HSM invocation keys.

[T] Toggles between the default ([Scroll Lock] [Scroll Lock])

and alternate ([Ctrl] [Ctrl]) Port Switching keys.

[F2] Enables Mac keyboard emulation.

[F3] Enables Sun keyboard emulation

[F10] Automatically detects and sets the keyboard operating

platform.

[F4] Lists the current switch settings via the paste function of a

text editor.

[F5] Performs a reset on all USB devices.

[F6] [nn] [Enter] Sets the keyboard language.

Note: nn is a two-digit number that represents one of the

following keyboard language code: US English: 33;

French: 08; Japanese: 15.

[B] Enables/Disables the buzzer.

[X] [Enter] Enables/Disables the port switching keys.

[R] [Enter] Resets the hotkey settings to their default status.

[u] [p] [g] [r] [a] [d] [e] [Enter]

Invokes Firmware Upgrade Mode. See The Firmware

Upgrade Utility, page 33, for full details.

[D] Invokes Video DynaSync, ATEN’s exclusive technology

that eliminates boot-up display problems and optimizes

resolution when switching between ports.

[E] Enables/Disables the Power on Detection feature. See

Power on Detection, page 27 for details.

[S] Toggles between the default and alternate manual port

selection pushbutton settings.

[M] Enables/Disables mouse emulation.

[W] Enables/Disable mouse port-switching.
