CS1762A / CS1764A User Manual
26
Firmware Upgrade Mode
To set the CS1762A / CS1764A to Firmware Upgrade Mode, do the following:
1. Invoke HSM (see page 22).
2. Key in: upgrade
3. Press [Enter]. The orange front panel LEDs flash to indicate Firmware
Upgrade Mode is in effect.
Note: To exit Firmware Upgrade Mode, you must power off the switch.
See The Firmware Upgrade Utility, page 33, for details.
Restore Default Settings
To reset the CS1762A / CS1764A to its default hotkey settings, do the
following:
1. Invoke HSM (see page 22).
2. Press [R] [Enter].
See Hotkey Default Settings, page 46
Video DynaSync
Video DynaSync is ATEN’s exclusive technology that eliminates boot-up
display problems and optimizes resolution when switching between ports. To
invoke Video DynaSync, do the following:
1. Invoke HSM (see page 22)
2. Press [D].
Note: If the monitor is disconnected and reconnected, the CS1762A /
CS1764A re-executes Video DynaSync.
Alternate Manual Port Selection Settings
To toggle between the default and the alternative front panel pushbutton
manual port selection settings, do the following:
1. Invoke HSM (see page 22)
2. Press [S].
See Alternate Manual Port Selection Settings, page 17, for full details.
