CS1762A / CS1764A User Manual
iv
Package Contents
The CS1762A / CS1764A package consists of:
1 CS1762
A / CS1764A USB DVI KVMP
TM
Switch
2 Custom KVM Cables sets (DVI-D) (CS1762
A)
4 Custom KVM Cable Sets (DVI-D) (CS1764
A)
1 Power Adapter
1 User Instructions*
Check to make sure that all the components are present and that nothing got
damaged in shipping. If you encounter a problem, contact your dealer.
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit, and/or any of the
devices connected to it.
* Features may have been added to the CS1762A / CS1764A since this manual
was printed. Please visit our website to download the most up-to-date version
of the manual.
© Copyright 2005-2013 ATEN® International Co., Ltd.
Manual Part No. PAPE-0231-AT7G
Printing Date: 2013-12-09
ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved.
All other brand names and trademarks are the registered property of their respective owners.
