Chapter 3. Basic Operation

Port ID Numbering

Each KVM port section on the CS1762A / CS1764A switch is assigned a port

number. (1 or 2 for the CS1762

A; 1 to 4 for the CS1764A). The port numbers

are marked on the rear panel of the switch (see page 8).

The Port ID of a computer is derived from the KVM port number it is

connected to. For example, a computer connected to KVM port 2 has a Port ID

of 2.

The Port ID is used to specify which computer gets the KVM, USB peripheral,

and audio focus with the Hotkey port selection method (see page 20 for

details).

Alternate Manual Port Selection Settings

When Hotkey Setting Mode has been activated, pressing [S] will invoke the

alternative front panel pushbutton manual port selection functions as follows

(see page 26, also):

 Press and hold a port selection pushbutton for more than 2 seconds to

bring the KVM, audio and USB focus to the computer attached to its

corresponding port.

 Press a port selection pushbutton twice to bring the audio focus to the

computer attached to its corresponding port.

 Press a port selection pushbutton once to bring only the KVM focus to the

computer attached to its corresponding port.

 Press and hold port selection pushbuttons 1 and 2 for more than 2 seconds

to start Auto Scan Mode, see page 21 for details.
