CS1762A / CS1764A User Manual
42
Specifications
Function CS1762A CS1764A
Computer Connections 2 4
Port Selection Front Panel Pushbuttons; Hotkey
Connectors Console
Ports
KB 1 x USB Type A F
(White; front panel)
1 x USB Type A F
(Black; rear panel)
Video 1 x DVI-I F (white)
Mouse 1 x USB Type A F
(white; front panel)
1 x USB Type A F
(Black; rear panel)
Speakers 1 x Mini Stereo Jack F
(Green; rear panel)
2 x Mini Stereo Jack F
(Green; 1 x front panel, 1
x rear panel)
Mic. 1 x Mini Stereo Jack F
(Pink; rear panel)
2 x Mini Stereo Jack F
(Pink; 1 x front panel, 1 x
rear panel)
KVM
Ports
KB/
Mouse
2 x USB Type B F
(White)
4 x USB Type B F (White)
Video 2 x DVI-I F (White) 4 x DVI-I F (White)
Speakers 2 x Mini Stereo Jack F
(Green)
4 x Mini Stereo Jack F
(Green)
Mic. 2 x Mini Stereo Jack F
(Pink)
2 x Mini Stereo Jack F
(Pink)
Power 1 x DC Jack 1 x DC Jack
USB Hub 2 x USB Type A F
(Black, rear panel)
2 x USB Type A F (White;
1 x front panel, 1 x rear
panel)
Switches Selected 2 x Pushbutton 4 x Pushbutton
LEDs On Line / Selected 2 (Orange) 4 (Orange)
USB Link 2 (Green) 4 (Green)
Emulation KB / Mouse USB
Video 1920 x 1200
Scan Interval 1–99 secs. (5 secs. default)
Power Consumption DC 5.3V, 9.0 W DC 5.3V, 10.7 W
