Appendix
45
When switching ports,
the monitor does not
display.
Monitor is new or this
is the first time
installation.
Switch ports again and wait two or
more seconds for the monitor’s EDID
to pass to the PC.
The monitor’s EDID
has not passed
through to the PC
when switching ports
Use the [d] hotkey to invoke Video
DynaSync one more time or switch to
another PC to reconnect the CS1762
A
/ CS1764
A. See HSM Summary
Table, page 28.
When switching ports,
there is a several
second delay before
the change happens.
This can occur when
keyboard emulation is
disabled.
Use the [F10] hotkey to enable
keyboard emulation. See HSM
Summary Table, page 28.
When switching ports
with the mousewheel,
and I want to switch
across two ports (from
Port1 to Port 3, for
example), sometimes
the change doesn’t
happen.
The switch needs
more time to process
the mouse input.
Wait 3 – 4 seconds between ports
before clicking for the next port.
Symptom Possible Cause Action
