1
Chapter 1
Introduction
Overview
The KVM Over the NET™ series of switches are IP-based KVM control units
that allow both local and remote operators to monitor and access multiple
servers from a single console. A single KN4140v can control up to 40 servers,
and by cascading up to 40 compatible 16 port switches, as many as 640 servers
can be controlled on a complete two stage installation.
The switches in this series are differentiated according to the number of buses
they support and the number of KVM ports they provide – as shown below:
Model Bus Support KVM Ports
KN2124v 1 Local; 2 Remote 24
KN2140v 1 Local; 2 Remote 40
KN4124v 1 Local; 4 Remote 24
KN4140v 1 Local; 4 Remote 40
KN2116v 1 Local; 2 Remote 16
KN2132v 1 Local; 2 Remote 32
KN4116v 1 Local; 4 Remote 16
KN4132v 1 Local; 4 Remote 32
KN2116
A 1 Local; 2 Remote 16
KN2132 1 Local; 2 Remote 32
KN4116 1 Local; 4 Remote 16
KN4132 1 Local; 4 Remote 32
