Aten KN2132v [241/316] Gui hotkey summary table

Chapter 12. Port Operation

223

Recalling the Port Access Page

To dismiss the toolbar and bring back the Port Access page, do one of the

following:

 Tap the GUI Hotkey once.

 From the toolbar, click the icon that recalls the Port Access page (see The

Toolbar Icons, page 220).

The toolbar closes, and the Port Access Page appears.

GUI Hotkey Summary Table

The following table presents a summary of the GUI Hotkey actions after you

have accessed a port. See User Preferences, page 121 to set the GUI Hotkey.

To... Do This...

Open the Toolbar Click the GUI Hotkey twice

Open the Port

Access Page

The Toolbar is open Click the GUI Hotkey once

The Toolbar is not open Click the GUI Hotkey three times
