Chapter 2. Hardware Setup
25
Single Stage Installation
In a single stage installation, there are no additional switches are cascaded from
the original switch. To set up a single stage installation, refer to the installation
diagrams starting on page 27 (the numbers in the diagram correspond with the
numbers of the instruction steps), and do the following:
1. For the KN2124v, KN2140v, KN4124v or KN4140v, use the 5-in-1
Console Cable supplied with the package to connect your Local Console
devices to the unit. (See KN2124v / KN2140v / KN4124v / KN4140v Single
Stage Installation Diagram, page 27.)
For the KN2116v, KN2132v, KN4116v, and KN4132v plug your Local
Console’s keyboard, monitor, and mouse into the unit’s Console Ports.
Each port is color coded and marked with an appropriate icon.
(See KN2116v / KN2132v / KN4116v / KN4132v Single Stage Installation
Diagram, page 28)
For the KN2116
A, KN2132, KN4116, and KN4132, plug your Local
Console’s keyboard, monitor, and mouse into the unit’s Console Ports.
Each port is color coded and marked with an appropriate icon.
(See KN2116A / KN2132 / KN4116 / KN4132 Single Stage Installation
Diagram, page 29)
Note: 1. You can use any combination of keyboard and mouse
connections. For example, you can use a PS/2 keyboard with a
USB mouse.
2. USB keyboards and mice can plug into the USB ports on the front
panel, as well as into the ports in the console port section.
3. The KVM Over the NET™ switch does not support distances that
exceed 20m between itself and the local monitor.
2. Use Cat 5e cable to connect any available KVM port to a KVM Adapter
Cable that is appropriate for the server you are installing (see the table on
page 10 for details).
Note: 1. If you are using a KA7120, KA7130, KA9120, KA9130, or
KA9131 Adapter Cable, refer to page 278 for mouse pointer
synchronization information.
2. If you are using a KA9131 Adapter Cable, refer to page 259 for
video and mouse adjustment information.
