Chapter 1. Introduction
5
Features
Hardware
High port density – RJ-45 connectors and Cat 5e/6 cable for up to 32 ports
in a 1U housing
Two or four separate buses for remote KVM over IP access
Two 10/100/1000 Mbps NICs for redundant LAN or two IP operation
Blade server support
Supports PS/2, USB, Sun Legacy (13W3) and serial (RS-232)
connectivity
Local console provides PS/2 and USB keyboard and mouse support
Supports multi-platform server environments: Windows, Mac, Sun, Linux
and VT100 based serial devices
High video resolution – up to 1600 x 1200 @ 60Hz – 32 bit color depth for
the local console; up to 1600 x 1200 @ 60Hz with 24 bit color depth for
remote sessions, at up to 50 m
Monitor and control up to 16 or 32 computers on a single level, or control
up to 512 computers in a cascade*
* Cascade-compatible KVM Switches include the following: CS9134,
CS9138, CS88A, KH1508, KH1516, KH1508A, and KH1516A
Management
Up to 64 user accounts – up to 32 users simultaneously share the control
End session feature – administrators can terminate running sessions
Event logging and Windows-based Log Server support
Critical system event notification via SMTP email; SNMP trap and Syslog
support
Multi Display for viewing extended monitors in a remote session
Customizable event notification
Firmware upgradable
Out-of-Band Access-Modem dial-in/dial out/dial back support
Adapter ID Function: Stores port information allowing administrators to
relocate the servers to different ports, without having to re-configure the
adapters and switches.
