KVM Over the NET™ User Manual
250
KN2132v / KN4132v
Function KN2132v KN4132v
Computer
Connections
Direct 32
Max 512
Port Selection Pushbutton / GUI / Hotkey
Connectors Console
Port
Keyboard 1 x 6-pin Mini-DIN Female (Purple)
1 x USB Type A Female (White)
Video 1 x HDB-15 Female (Blue)
Mouse 1 x 6-pin Mini-DIN Female (Green)
1 x USB Type A Female (White)
KVM Port 32 x RJ-45 Female (Black)
Power 2 x 3-prong AC socket
LAN 2 x RJ-45 Female (Black)
PON 1 x RJ-45 Female (Black)
Modem 1 x RJ-45 Female (Black)
USB 3 x USB Type A Female (White)
Switches Reset 1 x Semi-recessed Pushbutton
Power 2 x Rocker Switch
Port Selection 2 x Pushbutton
LEDs On Line 32 (Green)
Selected 32 (Red)
Power 1 (Blue)
Link
10 / 100 / 1000 Mbps
2 (Red / Red + Green / Green)
Emulation Keyboard/Mouse PS/2 / USB (PC, Mac, Sun) / Serial
Video 1600x1200 @ 60Hz
Scan Interval 1–255 secs
I/P Rating 100–240VAC; 50–60Hz; 1.0A
Power
Consumption
Single Power 110V / 33.40W
230V / 34.20W
110V / 45.80W
230V / 46.30W
Dual Power 110V/42.2W
230V/43W
110V/54W
230V/56W
Environment Operating Temp. 0–50° C
Storage Temp. -20–60° C
Humidity 0–80% RH
Physical
Properties
Housing Metal
Weight 5.59 kg 5.63 kg
Dimensions L x W x H 43.36 x 41.35 x 4.40 cm (19" 1U)
