Chapter 10. Maintenance

211

Ping

The Ping menu item lets you check the network status of devices on the KVM

Over the NET™ switch installation:

To ping a device, do the following:

1. Key the device’s IP Address or Host Name into the text entry box.

2. Click OK.

The ping results display in the Result panel.

Note: This feature is only available on firmware version 1.7.168 and below
