Installing the RS-232 Controller

In order to use the RS-232 serial interface to attach a high-end

controller (such as a PC) to the VS0108HA, use a serial cable

such as a modem cable. The end connecting to the VS0108HA

should have a 9-pin male connector. Connect this to the serial

interface on the rear of the VS0108HA. Refer to number 4 on the

diagram on page 12.

Note: To configure the controller serial port, see page 14.

RS-232 Serial Interface

The VS0108HA’s built-in bi-directional RS-232 serial interface

allows system control through a high-end controller, PC, and/or

home automation / home theater software package.

Configuring the Serial Port

The controller’s serial port should be configured as follows:

Switch Port

The available formulas for Switch Port commands are as follows:

Switch Command + Output Command + Port Number +

Control

For example, to turn on output port 02, type the following:

sw o02 on

-or-

For example, to turn off output port 01, type the following:

sw o01 off

Baud Rate 19200

Data Bits 8

Parity None

Stop Bits 1

Flow Control None
