Aten VS0108HA [15/20] Baud rate setting commands
![Aten VS0108HA [15/20] Baud rate setting commands](/views2/1211532/page15/bgf.png)
- 15 -
Baud Rate Setting Commands
You can set up the VS0108HA baud rate via RS-232.
The formula for Baud Rate setting commands is as follows:
Baud + Baud Rate Setting value [Enter]
For example, to set the baud rate to 9600, input the following:
baud 9600 [Enter]
The following tables show the possible values for the Control
string
:
The following table shows the available command list:
Command Description
baud Power On Detection command
Control Description
9600 Uses 9600 baud rate
19200 Uses 19200 baud rate (default)
38400 Uses 38400 baud rate
115200 Uses 115200 baud rate
Command Control Enter Description
baud 9600 [Enter] The VS0108HA implements 9600
baud rate setting
baud 19200 [Enter] The VS0108HA implements 19200
baud rate setting (default)
baud 38400 [Enter] The VS0108HA implements 38400
baud rate setting
baud 115200 [Enter] The VS0108HA implements 115200
baud rate setting
