- 19 -
ATEN Default EDID
The ATEN default EDID configuration can be selected via the RS-
232 command line (see EDID Commands, page 16):
Default EDID No. Configuration
00 720p video, 2 ch audio (default)
01 1080p video, 2 ch audio
02 1080p video, 5.1 ch audio
03 1080p video, 7.1 ch audio
04 1080i video, 2 ch audio
05 1080i video, 5.1 ch audio
06 1080i video, 7.1 ch audio
07 3D 1080p, 2 ch audio
08 3D 1080p, 5.1 ch audio
09 3D 1080p, 7.1 ch audio
10 1024 x 768 DVI format
11 1280 x 1024 DVI format
12 1920 x 1080 DVI format
13 1920 x 1200 DVI format
