- 14 -
The following table shows the possible values for the Switch Port
commands:
The following table shows the available command list:
Note: 1. Each command string can be separated with a space.
2. The Port Number command string can be skipped, and
the default value will be used.
Command Description
sw Switch command
Output Command Description
o Output command
Port Number Description
yy 01-08 port
* All output ports (default)
Control Description
on Turn on the display
off Turn off the display
Command Input Port Control Enter Description
sw o yy on [Enter] Turn on display port yy
sw o yy off [Enter] Turn off display port yy
sw o * on [Enter] Turn on all displays
sw o * off [Enter] Turn off all displays
