VC010 / VC060 / VC080 User Manual
5
Front View
No. Component Description
1 RS-232 port Connect one end of the provided RS-232
Configuration Cable to this port and the other end to
your PC’s serial port for RS-232 Command Control.
2 VGA IN port /
DVI IN port /
HDMI IN port
Connect your VGA / DVI / HDMI source device to this
port.
VC010
VC060
VC080
1
2
1
2
1
2
