VC010 / VC060 / VC080 User Manual
10
EDID Wizard
The EDID Wizard application can downloaded from the ATEN website. It
enables users to view detailed information about the attached display and edit
them accordingly. Save time by using the EDID Wizard to automatically
retrieve a display's EDID. Furthermore, you can use the EDID Wizard to
preconfigure up to 3 EDID settings for later use, thus eliminating delays when
changing displays.
EDID Wizard Menu
The OSD menu options are shown in the table below.
Menu Page Sub-Menu Page(s)
EDID Setting Location ATEN Default / Set 1 / Set 2 / Set 3
Resolution Resolution
Audio Audio Format (1-3)
Position EDID Vendor / Product Identification
EDID Structure/ Revision
Basic Display / Feature
Color Characteristics
Established Timings
Standard Timings
Detail Timing / Display Description (1-3)
Monitor Description (1-2)
CEA Display Support
Video Data
Audio Data
Speaker Allocation
Vendor Specific Data
Detail Timing / Display Description (1-5)
