Chapter 3

Operation

Overview

The VGA/DVI/HDMI EDID Emulator offers an easy and flexible EDID

selection method using the front panel pushbuttons. You can select the default

ATEN EDID configuration or one of three customized EDID settings (stored

via the EDID Learn Pushbutton or the EDID Wizard). Upgrade the firmware

conveniently through the RS-232 serial interface. The VC010 / VC060 /

VC080 is set to use the ATEN EDID configuration by default at initialization.

EDID Panel Selection

To select an EDID via the front panel, press the EDID Set pushbutton to toggle

between the Default and EDID Sets 1~3. The LEDs indicate which setting is

currently selected.

 Default- the EDID is set to the ATEN default configuration

 LED 1 ~ 3 - the EDID is customized; see the next section for details on

how to customize and store EDIDs for later use.

EDID Learn Pushbutton

You can automatically store a display’s EDID for later use by pressing the

EDID Learn Pushbutton located in the top panel. Follow these steps:

1. Attach the video display/monitor you want to use to the VC010 / VC060 /

VC080.

2. Select the EDID Set (1~3) into which you want to store the configuration

– do this by pressing the EDID Learn Pushbutton. The LED lights up to

indicate it is the active position.

3. Press the EDID Learn Pushbutton for more than three (3) seconds. The

selected LED flashes to indicate that the settings are being captured and

stored.

4. Do these steps (1 to 3) for each display/monitor EDID that you want to

store. You can also use the EDID Wizard’s EDID Program feature.
