VC010 / VC060 / VC080 User Manual
6
Rear View
No. Component Description
1 VGA OUT port /
DVI OUT port /
HDMI OUT port
Connect your VGA / DVI / HDMI display to this port.
2 Power Jack Plug in the power adapter to the power jack and use
the switch to power on the VC010 / VC060 / VC080.
VC010
VC060
VC080
1
2
1
2
1
2
