VC010 / VC060 / VC080 User Manual
22
Preparation
To prepare for the firmware upgrade, do the following:
1. Use the Firmware Upgrade Cable provided with this unit to connect a COM
port on your computer to the Firmware Upgrade Port of your VC010 /
VC060 / VC080.
2. Press and hold the Learn/Select button.
3. Plug the power adapter into the VC010 / VC060 / VC080 to power the
unit.
VC010
VC060
VC080
