VC010 / VC060 / VC080 User Manual

Save to Device

The Save to Device button enables you to use an EDID configuration for the

duration of the session. Unlike the File > Save/Save as menu option, the Save

to Device button does not save the configuration into a file.

Note: When editing the rest of the screens in the application, make sure you

use the File > Save/Save as menu option to make an EDID

configuration available for later use. Otherwise, you will have to re-

enter the EDID configuration values.

EDID Programming

You can use the Summary screen to automatically retrieve and save the EDID

settings of a connected monitor/display device. To do this, follow these steps:

1. In the Summary screen, under the Location column, check the EDID Set

(1~3) into which you want to store the configuration.

2. Click the Retrieve EDID from Display button. This captures the EDID

settings of the device currently connected to the VC010 / VC060 / VC080.

3. The Summary screen displays the acquired settings. Click the Save to

Device button to use the configuration for the duration of the session, or

go to File > Save / Save as menu option to save the configuration to a file,

making it available for later use.

Note: See EDID Learn Pushbutton, page 9 for retrieving and storing EDID

settings using the front panel pushbutton.
