31
Using BIOS
SATA Configuration
Use this item to show the mode of serial SATA configuration options.
SATA Configuration
Onchip SATA Channel [Enabled]
SATA Mode [IDE]
SATA Port1 Not Present
SATA Port2 Not Present
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Enable/Disable SATA Controller
Main Advanced Chipset Frequency/Voltage Control Boot Security Save & Exit
Version 2.10.1208. Copyright (C) 2010, American Megatrends, Inc.
Onchip SATA Channel (Enabled)
Use this item to enabled or disable the onchip SATA channel.
SATA Mode (IDE)
Use this item to select SATA mode.
SATA Port1~2 (Not Present)
This motherboard supports four SATA channels and each channel allows one SATA
device to be installed. Use these items to configure each device on the SATA channel,
and each channel allows one SATA device to be installed. Use these items to configure
each device on the SATA channel.
Press <Esc> to return to the Advanced Menu page.
+/- :Change Opt.
Enter : Select
F1:General Help
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
